Pixel-Free LED Trim Control RGBW Smart Strip Light Sample Kit
Pixel-Free LED Trim Control RGBW Smart Strip Light Sample Kit

Pixel-Free LED Trim Control RGBW Smart Strip Light Sample Kit

The New Pixel-Free LED Trim Control RGBW Smart Strip Light is a beautiful balance of flexibility &...
SKU: LDF200-S
Availability: 5 In Stock
$64.99
$64.99
Please hurry! Only 5 left in stock
Subtotal: $64.99
10 customers are viewing this product

Free Shipping

Free domestic ground standard shipping on orders over $50

Pixel-Free LED Trim Control RGBW Smart Strip Light Sample Kit

Pixel-Free LED Trim Control RGBW Smart Strip Light Sample Kit

$64.99

Pixel-Free LED Trim Control RGBW Smart Strip Light Sample Kit

$64.99

The New Pixel-Free LED Trim Control RGBW Smart Strip Light is a beautiful balance of flexibility & durability, while providing a perfectly diffused strip light that mimics neon. The flexible silicon housing makes the strip indoor or outdoor rated, capable of being used as an architectural accent, lobby lighting, retail or trade show lights, among many others. The strip is easily embedded into various materials, and the low heat dissipation means it remains safe when applying directly to woods, metals or plastics. The perfectly diffused surface means it makes a great direct-view lighting strip eliminating any shadowing effect and allows for full pixel control over the entire strip. Create chasing effects for wayfinding, or accentuate your building's signage with the full color range of the RGBW (Red, Green, Blue, White) chip integrated inside.

The IP65 rated strip is great for nearly any environment, which also has excellent UV resistance, anti-corrosive, resistant to saline, acids, alkali, and more. Working temperature is 20 ~ 45°C and has a long lifespan (36,000 Hours) and comes with a 3-Year Warranty. 3-Conductor Design (+, -, Data) allows for full external pixel control via SPI based protocol. This strip uses a P943 Protocol which is often compatible with the TM1809 protocol. Bending diameter should be at least 60mm.

Dimensions: 12x20x500mm (0.5" x .8" x 19.5")
Voltage: 12V
Minimum Cutting Distance: 50mm (~2")
Max Power Consumption: 14.4W/m
Outdoor Rating: IP65
Minimum Bending Diameter: >60mm (~2.4")
Viewing Angle: 116°
LED Lifespan: 36,000 Hours
Certifications: CE, RoHS, UL
